Structure diagram
Technical Data Sheet
| model | Pipe diameter (mm) | Filtration area (㎡) | Rated flow (kg / h) | System pressure | Biphenyl jacket pressure | Allowable differential pressure | Operating temperature | Filtration accuracy |
| CPF-PT-19J-H | 80 | 19 | 110T / d | Max25Mpa | ≤0.6Mpa | Max8Mpa | ≤320 ℃ | 3 ～ 100um |
| CPF-PT-31J-H | 80 | 31 | 180T / d | |||||
| CPF-PT-37J-H | 80 | 37 | 220T / d | |||||
| CPF-PT-48J-H | 100 | 48 | 280T / d | |||||
| CPF-PT-61J-H | 120 | 61 | 340T / d | |||||
| CPF-PT-80J-H | 125 | 80 | 400T / d | |||||
| CPF-PT-95J-H | 125 | 95 | 450T / d | |||||
Scope of application:
Polymer granulation, polymer direct spinning, continuous polycondensation (such as PET, PBY, Nylon6), special fibers, carbon fibers, dope, milk fibers, soybean fibers, and petrochemical industries.
heating method:
Both heating oil circulation heating and biphenyl circulation heating can be selected.
